Product Description:
|
|
■Tinned ,annealed,stranded or solid copper conductor，Top-coated.
|
|
■Rated temperature:105℃.
|
|
■Rated voltage:300Volts
|
|
■Passes UL&CUL， HORIZonTAL flamt test
|
|
說明：
|
|
■導體使用單股或絞線裸銅或鍍錫銅或先絞后鍍。
|
|
■額定溫度：105℃
|
|
■額定電壓：300Volts
|
|
■可通過UL 及 CUL ，水平燃燒測試
|
|
Applications:
|
|
■Internal wiring of appliances
|
|
Computers.
|
|
應用：
|
|
■用于電子，電器，電腦設備內部連接。
|
|
UL Style& CUL Type
|
線號
|
Conductor
導體
|
Pitch
間距
|
Cores
芯數
|
Insulation Thickness絕緣厚度
|
Overall
Dimeter
完成外徑
|
Conductor
Resistance at 20℃導體電阻
|
|
線數/線徑
|
|
AWG
|
mm
|
NO
|
mm
|
mm
|
Ω/KM
|
|
UL4411 CUL AWM I/A
|
24
|
7/0.203或
11/0.16
|
1.6或
1.5
|
2
|
0.38
|
1.5×4.7/4.5
|
94.20
|
|
3
|
1.5×4.7/4.5
|
|
4
|
1.5×6.3/6.0
|
|
5
|
1.5×7.9/7.5
|
|
6
|
1.5×9.5/9.0
|
|
7
|
1.5×11.1/10.5
|
|
8
|
1.5×12.7/12
|
|
9
|
1.5×14.3/13.5
|
|
10
|
1.5×15.9/15
|
|
11
|
1.5×17.5/16.5
|
|
12
|
1.5×19.1/18
|
|
24
|
7/0.203
|
2.00
|
2
|
0.38
|
1.5×3.5
|
94.20
|
|
3
|
1.5×5.5
|
|
4
|
1.5×7.5
|
|
5
|
1.5×9.5
|
|
6
|
1.5×11.5
|
|
7
|
1.5×13.5
|
|
8
|
1.5×15.5
|
|
9
|
1.5×17.5
|
|
10
|
1.5×19.5
|
|
11
|
1.5×21.5
|
|
12
|
1.5×23.5
|
|
13
|
1.5×25.5
|
|
14
|
1.5×27.5
|
|
15
|
1.5×29.5
|
|
16
|
1.5×31.5
|
|
17
|
1.5×33.5
|
|
24
|
7/0.203或
11/0.16
|
2.54
|
2
|
0.38
|
1.5×4.0
|
94.20
|
|
3
|
1.5×6.5
|
|
4
|
1.5×9
|
|
5
|
1.5×11.5
|
|
6
|
1.5×14
|
